Intuitive system
The WasteFlix WF-70LX Semi-Automatic Horizontal Baler is engineered to produce bales with dimensions of 1500mm x 1100mm x 1100mm (L x W x H), capable of reaching weights of up to 850kg. This high-capacity baler is designed to efficiently fill a shipping container with fewer than 30 bales, unlike competitor machines that typically require 48 bales and often fall short of the optimal shipping weight of 25 tonnes.
Durability and efficiency are at the core of the WF-70LX, which comes equipped with wear plates as standard for exceptional serviceability. The machine features a full bale eject system and a portcullis door incorporating anti-wire snap technology, addressing the common issue of bale wire snapping during ejection. Additionally, ripping teeth are included as standard, enabling the WF-70LX to handle a wide variety of waste materials with ease.
The WF-70LX offers flexible feeding options, starting with a spacious 2000mm x 1100mm feed opening, perfect for bulky materials. Additional feeding options such as conveyor feed, trunnion bin lifter, or mechanical feed are also available to meet diverse operational needs. The baler’s controls include multi-product selection capabilities, ensuring that maximum bale weights are consistently achieved across different materials.
Proudly built in the UK, the WasteFlix WF-70LX promises exceptional service, reliability, and long-term performance—reflecting our commitment to quality and customer satisfaction.
Technical Data
Baler Dimensions
L: 5500mm
W: 1650mm
H: 2570
Bale Dimensions
L: 1250mm
W: 1100mm
H: 1100mm
Bale Weight
Up to 600kg
Bale Discharge
Full Eject
Wire/Tape Tying
5 Horizontal Wire
Power Supply
32 AMP, D Type Breaker
Motor Power
11 kW
Compaction Force
50 Tonnes
